Proudly built in North America, the TDR-22 is the best value in a Roller Finishing Mower for large-size fields and natural grass production. Unparalleled performance is due to the many standard features that have been field proven over many years of productive use. Full width 6” diameter steel rollers front and back follow the ground contours and help prevent scalping while they smooth the field surface and aid in moisture retention. A high blade tip speed (18,300 fpm) ensures a high quality finish cut, while a choice of four blade types allows the TDR-22 / TDR-22G to be tailored to meet your specific requirements... just to name a few. Together, these changes make the TDR-22 more productive, easier to operate, maintain, and ultimately a better value for natural grass producers worldwide.
AVAILABLE IN PAINTED OR GALVANIZED DECK SHELL FINISH
Pro Lift-N-Turn is a popular standard feature on the TDR-22, the mechanical stops of the Pro Lift-N-Turn system protect the mower while the operator protects the headlands.
The deck pull points are positioned slightly ahead, but much closer to the deck than how competitive models are designed. This makes the TDR-22 better suited for soft ground conditions.
Simplifying service and reducing maintenance requirements were key design objectives to minimize ownership costs, and the TDR-22 delivers!
For producers who grow in sandy, or acidic soil conditions, the bolt on deck design allows for inexpensive replacement of the deck if necessary.
What’s old is new – applies to the TDR-22 especially when it comes to features that give high reliability and low cost of ownership.
|Part Number:||526822 (Painted Decks) 526822G (Galvanized Decks)|
|Recommended PTO H.P.:||65 to 75|
|Mowing Capacity: * (Assumes no overlap or turning)||4 mph 10.7 acres per hour *
6 mph 16.0 acres per hour *
7.5 mph 20 acres per hour *
|Cut Height Range:||1/2" to 4"|
|Transport Tires:||LT305/70R-16 Automotive high floatation|
|Transport Height:||10' 2"|
|Std. Equipment:||The tractor is required to have a single hydraulic float circuit.
